Datong Hydraulic 4140 Hydraulic Cylinder Rod /Hard Chrome Bar/Hard Chrom...

Comments

Post a Comment

Popular posts from this blog

Telescopic Hydraulic Cylinder Application And Pressures

  A  telescopic hydraulic cylinder  can be used in several types of applications that require a linear force to be applied over a long distance. While a rod cylinder could potentially perform the job it may be too long when fully collapsed, where as a telescopic cylinder will typically be significantly shorter when in the same position. The collapsed package size plus long stroke capability of a telescopic cylinder is one of the advantages the design offers over a rod cylinder. Rod cylinders will apply the same force throughout their stroke, assuming that system pressure remains constant. While it is possible to design a telescopic cylinder that applies a constant force, the cost is significantly increased. Generally a  telescopic cylinder  will be used in applications where a constant force is not required. Both single acting and double acting telescopic cylinders are used in non-constant force applications. The most common of these in mobile applications are d...
Read more

Inspection steps of 4140 hard chrome plated bar

1. After the  4140 hard chrome plated bar  piston is processed, the water pressure experiment should be stopped, and the water pressure is generally L 5 times the maximum working pressure. 2. When the chromium-plated rod piston shows cracks, it should generally be scrapped; the cylindrical surface of the piston is worn due to the friction of the piston ring, which is usually not repaired; when the diameter of the cylinder bore is increased, it needs to be selected according to the increased diameter New bracket; repair only when the chrome-plated rod piston is worn or the chrome-plated rod piston ring groove and cylindrical piston pin hole are worn. 3. When the chrome-plated rod piston is scratched or scratched, you can first use a file to file the abrasion and nodules carefully, and then use a whetstone to quietly polish and lubricate.
Read more

40CR ALLOY STEEL SPECIFICATION

  40Cr steel  is a kind of Chinese GB standard alloy steel for engineering and machinery purpose, and one of the most widely used steel grades. For 40Cr material hardness, specifications and equivalent, please see the table below. After quenching and tempering treatment, 40Cr steel has good comprehensive mechanical properties, low temperature impact toughness, low notch sensitivity, good hardenability, and high fatigue strength in cold oil. When water cooling, the complicated shape of the parts is prone to cracks, the cold bending plasticity is medium, and the cutting workability after normalizing is good, but the weldability is poor, should be preheated before welding, and is generally used in the state of quenching and tempering. DATASHEET & SPECIFICATION The tables below list 40Cr alloy steel datasheet and specification including chemical composition, properties and heat treatment, etc. 40CR STEEL CHEMICAL COMPOSITION   Chemical Composition (%) Grade C % Si Mn Cr 4...
Read more
